Handheld laser rangefinder
Compact, lightweight and accurate laser rangefinder binoculars designed for golf, outdoor measurement, forestry survey, municipal engineering, communication maintenance and equipment install
-
Estimated Delivery:Jul 13 - Jul 17
-
Free Shipping & Returns: On all orders over $75
Handheld Laser Rangefinder Binoculars
Compact, lightweight and accurate laser rangefinder binoculars designed for golf, outdoor measurement, forestry survey, municipal engineering, communication maintenance and equipment installation.
Key Features
Long-Distance Measurement
Supports multiple ranging options up to 1000m, 2500m or 3000m depending on the model, making it suitable for both close-range and long-distance field applications.
Fast & Accurate TOF Technology
Built with Time-of-Flight laser ranging technology for quick response, high precision and stable distance measurement performance.
Clear Optical Viewing
Equipped with 6X or 7X optical magnification, wide field of view and multi-coated optical lenses for brighter, clearer and more comfortable observation.
Portable & Durable Body
The compact body is wrapped with non-slip, wear-resistant soft rubber material, offering a comfortable grip and reliable protection for outdoor use.
Multi-Function Outdoor Measurement Tool
Designed for professional and outdoor scenarios, this laser rangefinder binocular integrates multiple measurement functions in one compact device.
- Distance measurement
- Angle measurement
- Height measurement
- Speed measurement
- Slope correction measurement
- Optional ballistic calculation customization for selected models
Ideal Applications
Technical Specifications
| Specification | JB-KO Series | JB-LO Series |
|---|---|---|
| Measuring Range | 1m–1000m / 2500m / 3000m | 1–600m / 1000m / 2500m / 3000m |
| Measuring Accuracy | ≤400m: ±1m; ＞400m: ±d×0.3% | ≤1000m: ±1m; ＞1000m: ±d×0.3% |
| Optical Magnification | 7X | 6X |
| Objective Lens Diameter | 24mm | 22mm |
| Eyepiece Diameter | 13mm | 16mm |
| Exit Pupil Diameter | 3.4mm | 3.7mm |
| Field of View | 6.5° | 6.3° |
| Diopter Adjustment | +5D to -5D | +5D to -5D |
| Laser Type | 905nm, Class 1 Laser | 905nm, Class 1 Laser |
| Display | Low-transmission LCD | Low-transmission LCD |
| Inclination Range | ±60° | ±60° |
| Charging Port | TYPE-C | TYPE-C |
| Protection Rating | IP65 | IP65 |
| Operating Temperature | -40°C to +50°C | -10°C to +50°C |
Frequently Asked Questions
Q1: What measurement functions does this rangefinder support?
It supports distance measurement, angle measurement, height measurement, speed measurement and slope correction measurement.
Q2: Is it suitable for outdoor use?
Yes. The device features a compact body, anti-slip soft rubber wrapping and IP65 protection, making it suitable for outdoor measurement scenarios.
Q3: What type of laser does it use?
It uses a 905nm Class 1 laser.
Q4: Can the product be customized?
Selected models can support customized ballistic calculation functions according to project requirements.
